Product number: MUZ-AP42VGD2-A2
Mitsubishi Electric
| Cooling Capacity : | 4.20 kW |
|---|---|
| EER : | 3.53 |
| Heating Capacity : | 5.40 kW |
| Indoor/ Outdoor/ Other : | Indoor |
| Product Group : | Hi-Wall - Mitsubishi Electric |
| Refrigerant : | R32 |
Whether you need consistent heating or cooling for your home or office, the Mitsubishi Electric MSZ-AP Series delivers state-of-the-art technology.
With built-in Wi-Fi, an Anti-Allergy Enzyme Filter, and Dual Barrier Coating, it offers quiet operation, user-friendly controls, energy efficiency, and outstanding reliability.
Enjoy peace of mind with a 5-year parts and labour warranty.
| Product Group : | Hi-Wall - Mitsubishi Electric |
|---|
| Indoor/ Outdoor/ Other : | Indoor | Indoor Units Connectable (Quantity) : | 1 |
|---|---|---|---|
| Single Split / Multi Split : | Single Split |
| Compressor Type : | DC Scroll |
|---|
| Cooling Capacity : | 4.20 kW | Cooling Capacity (Min/Rated/Max) : | 0.90 - 4.20 - 4.80 kW |
|---|
| Max Current : | 10.0 A | Power Supply : | 220-240/1/50 V/Ph/Hz |
|---|---|---|---|
| Recommended Fuse : | 10 A |
| COP : | 3.78 | EER : | 3.53 |
|---|
| Number Of Fans : | 1 |
|---|
| Heating Capacity : | 5.40 kW | Heating Capacity (Min/Rated/Max) : | 1.30 - 5.40 - 6.00 kW |
|---|
| Depth : | 285 mm | Height : | 550 mm |
|---|---|---|---|
| Net Weight : | 10.5 kg | Weight : | 36 kg |
| Width : | 800 mm |
| Max Height Difference : | 12 m | Max Piping Length : | 20 m |
|---|
| Refrigerant : | R32 | Refrigerant Pipe Size : | 1/4 - 3/8 in |
|---|
| Temperature Range Cooling : | -10 - 46 °C | Temperature Range Heating : | -15 - 24 °C |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| split-systems-brochure-2025-ast-4314208.pdf | Brochures | 2.18 MB |
