Gree Inv Hyper+ R32 9.4kW Wall Split ID 1/4 x 5/8

Product number: GWH32QFXH-K6DNB2A/I

Gree

Product Group : Hi-wall - Gree Hyper
Cooling Capacity : 9.4 kW
EER : 3.8
Heating Capacity : 10.3 kW
Indoor/ Outdoor/ Other : Indoor
Pre-Equipped Wifi : Yes
Refrigerant : R32
Voltage : 230 V
Description
Usher the smart life into your home by choosing the Gree Hyper+ AI with remote control via WiFi, energy efficiency resulting economic operation and improved product longevity through a range of technologies designed to protect the units from moisture, dust, dirt and corrosive elements. All backed by Gree's 6 year warranty parts and labour warranty.
General Information
Product Group : Hi-wall - Gree Hyper Condensate Water Pump Provided : No
Pre-Equipped Wifi : Yes Remote Control : Yes
Additional Info
Indoor/ Outdoor/ Other : Indoor Single Split / Multi Split : Single Split
Air Volume/Air Flow
Air Flow : 1447 m³/h
Capacity
Cooling Capacity : 9.4 kW Cooling Capacity (Min/Rated/Max) : 2.1 - 9.4 - 12.2 kW
Heating Capacity : 10.3 kW Heating Capacity (Min/Rated/Max) : 2.6 - 10.3 - 12.0 kW
Cooling Capacity R32
R32 Cooling Capacity Rated : 9.4 kW
Electrical
Power Supply : 220-240/1/50 V/Ph/Hz Recommended Fuse : 20
Voltage : 230 V Voltage 50Hz : 230 V
Energy Efficiency/Performance
COP : 3.4 EER : 3.8
R32 SCOP : 3.4 R32 SEER : 3.8
Heating Capacity R32
R32 Heating Capacity Rated : 10.3 kW
Indoor Unit Attributes
Net Weight (IU) : 20 kg
Measurements
Depth : 253 mm Height : 326 mm
Net Weight : 20 kg Weight : 20 kg
Width : 1350 mm
Pipes
Max Pipe Length Without Additional Refrigerant : 10 m Max Piping Length : 25 m
Pipe Dimension : 6.35 x 15.80 mm
Power Input R32
R32 Power Input Rated Cooling : 2.4 kW R32 Power Input Rated Heating : 3.03 kW
Refrigerant
Refrigerant : R32 Refrigerant Charge : 1.9 kg
Refrigerant Pipe Size : 1/4 - 5/8 in
Sound Power/Pressure
Sound Power Level : 47 dB(A) Sound Pressure Level : 34 dB(A)
Sound Pressure Level (Low/Medium/High/Quiet) : 34/57 dB(A)
Wire
Wire Diameter Interconnection Cable : 3C + E
File name Document Type Extension Size
Gree-Hyper-AI-Brochure-8pp-2023-AU.pdf Brochures pdf 18.56 MB
