Description
077B Service thermostat no. 4
Danfoss T/Stat No 4
Product number: 077B7004
Danfoss
| Product Group : | Mech Controls - Temperature |
|---|
General Information
| Product Group : | Mech Controls - Temperature | Approval : | BEAB, CE, EAC, LLC CDC TYSK, cURus |
|---|---|---|---|
| Type : | B02 | Used For : | Absorption coolers |
Additional Info
| Family : | 077B |
|---|
Electrical
| Contact Function : | NC |
|---|
Logistical Information
| Commodity Code : | 90321080 | Country Of Origin : | SVK |
|---|---|---|---|
| EAN : | 5702424006587 | Gross Weight : | 0.14 kg |
Measurements
| Capillary Tube Length : | 59.1 in, 1500 mm | Net Weight : | 0.11 kg |
|---|---|---|---|
| Weight : | 0.11 kg |
Temperature
| Cold Cut In : | -5.5 °C | Cold Cut Out : | -11.0 °C |
|---|---|---|---|
| Warm Cut In : | 3.5 °C | Warm Cut Out : | -1.0 °C |
| File name | Document Type | Extension | Size |
|---|---|---|---|
| Barometric-Pressure-Information.pdf | Technical literature | 526.23 KB | |
| Service-kit-types-B0-B62.pdf | Technical literature | 1.95 MB | |
| Brochure-Electromechanical-cold-controls-en.pdf | Brochures | 3.2 MB | |
| Electrical-Safety-Certificate-UL-E31024.pdf | Conformity Declaration | 5.22 MB | |
| Manufacturer-s-Declaration-Danfoss-MD2012-2-EBD-A5.pdf | Conformity Declaration | 54.09 KB | |
| Manufacturer-s-Declaration-Danfoss-MD2016-China-RoHS-A02.pdf | Conformity Declaration | 67.82 KB | |
| EU-Declaration-Danfoss-EU-D-2018-11-A3.pdf | Conformity Declaration | 780.37 KB |
